Penn Station Concourse Improvements

True has worked on both Phase 1 and Phase 2 of the NY Penn Station Concourse Critical Improvements project. In Phase 1, True was asked to provide a boundary, topographic and utility survey of the area. Boundary lines were established as a base for future work on new lease area descriptions that will need to be created inside Penn Station. True provided a three-dimensional description of the new entrance on 33rd Street and the portion of the closed 33rd Street. True was asked to provide a Laser Scan of Penn Station both 1 PENN Plaza and 2 PENN Plaza including: Track Level, Platform level, Concourse levels, 33rd Street connecting Concourse and Main Gate Area. A high-resolution point cloud was provided for all areas that were scanned. A revit model drawing was created with True support in AutoCAD civil3D.

In Phase 2, True was tasked with a continuation of cross sectioning, topographic survey, boundary survey and utility survey including laser scanning and mapping of the Concourses, shops, offices and most back of house areas within Penn Station. True will prepare lease area descriptions from the model created by the laser scan. These areas included 1 PENN Plaza and 2 PENN Plaza- All parking garages, stairways, hallways, some utilities at sample locations above ceilings, the old Taxi Ramp, and some platforms and tracks and escalators as needed.
